Power Source

220 to 240 V AC, 50/60 Hz

Power Consumption

601 W (rated output),
113 W (based on EN62368)

Current Consumption

200 mA or less (when power switch is OFF)

Audio Input

LINE IN: 0 dB*/-20dB* switchable, 600 Ω, transformer balanced, RCA pin jack x 2
SPEAKER LINE IN: 40 dB* (100 V line), 65 kΩ, transformer balanced, removable terminal block (3P)

Rated Output

480 W

Audio Output

SPEAKER OUT: Low impedance (4 to 16 Ω)/High impedance(21 Ω), Removable terminal block(3 pins)
LINE OUT: 0 dB *, 600 Ω, unbalanced, RCA pin jack x 2

Frequency Response

50 Hz to 20 kHz ±3 dB (1/8 rated output)

Signal to Noise Ratio

90 dB or more (Master volume: min.)
76 dB or more (Master volume: max.) (A-weighted)

Distortion

1 % or less at 1 kHz, rated power (20 kHz LPF (AUX-0025)

Indicators

5-point LED output level meter, Power indicator, Emergency indicator, Thermal protection indicator, Over current protection indicator

Tone Control

Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz

Control Input

POWER REMOTE IN: No-voltage make contact input, open voltage: 35 V DC or less, short-circuit current: 10 mA or less, removable terminal block (4 pins)
EMERGENCY IN: Novoltage make contact input, open voltage: 35 V DC or less, removable terminal block (4 pins)

Control Output

POWER REMOTE OUT: Open collector output, withstand voltage׃ 30 V DC or less, control current׃ 25 mA or less, removable terminal block (3.50 mm, 4 pins)
EMERGENCY OUT: Open collector output, withstand voltage׃ 30 V DC or less, control current׃ 25 mA or less, removable terminal block (3.50 mm, 4 pins)

Operating Temperature

-10˚C to +40 ˚C (14 ˚F to 104 ˚F)

Operating Humidity

85 % RH or less (no condensation)

Finish

Panel: ABS resin, black
Case: Surface-treated steel plate, black, paint

Dimensions

420 (W) x 96.1 (H) x 313.1 (D) mm (16,54" x 3.78" x 12.33")

Weight

5 kg (11.02 lb)

Included Accessories

Power cord (2m (6.56 ft) x 1, Audio input removable terminal plug (5 mm, 2 pins) x 1, Control I/O removable terminal plug (3.5 mm, 4 pins) x 2, Speaker out removable terminal plug (5 mm, 3 pins) x 1, Volume control cover x 1

Optional Accessories

Rack mounting bracket: MB-25B, Perforated panel: PF-013B
